长工作距离平场复消色差APO金相物镜2X 5X 10X 20X 50X 100X 无限远校正，焦距=200mm,齐焦距离95mm
技术参数
|
品 名
|
数值口径
NA
|
工作距离
WD(mm)
|
焦距
f(mm)
|
分辨率
R(mm)
|
焦深
±D.F(μm)
|
波长范围 wavelength coverage(nm)
|
螺纹接口
screw
|
|
UL2X-1
|
0.055
|
33.7
|
100
|
6.1
|
90.9
|
400-700
|
M26x0.705
|
|
UL2X-2
|
0.055
|
36
|
100
|
6.1
|
90.9
|
400-700
|
M26x0.705
|
|
UL5X-1
|
0.14
|
33.6
|
40
|
2.2
|
14.03
|
400-700
|
M26x0.705
|
|
UL5X-2
|
0.14
|
45.3
|
40
|
2.2
|
14.03
|
400-700
|
M26x0.705
|
|
UL10X-1
|
0.28
|
33.4
|
20
|
1.2
|
3.5
|
400-700
|
M26x0.705
|
|
UL20X-1
|
0.34
|
29.5
|
10
|
0.8
|
2.38
|
400-700
|
M26x0.705
|
|
UL20X-2
|
0.45
|
20
|
10
|
0.61
|
1.35
|
400-700
|
M26x0.705
|
|
UL50X-1
|
0.50
|
18.8
|
4
|
0.7
|
1.1
|
400-700
|
M26x0.705
|
|
UL50X-2
|
0.55
|
13.3
|
4
|
0.61
|
0.9
|
400-700
|
M26x0.705
|
|
UL50X-3
|
0.67
|
10
|
4
|
0.5
|
0.61
|
400-700
|
M26x0.705
|
|
UL50X-4
|
0.80
|
4
|
4
|
0.42
|
0.43
|
400-700
|
M26x0.705
|
|
UL100X
|
0.70
|
7.1
|
2
|
0.5
|
0.56
|
400-700
|
M26x0.705
|
|
NIR UL20X-2
|
0.45
|
20
|
10
|
0.61
|
1.35
|
400-1064
|
M26x0.705
|
|
NIR UL50X-3
|
0.67
|
10
|
4
|
0.5
|
0.61
|
400-1064
|
M26x0.705
|
|
